The ultimate low cost satellite position system for  both leisure and professional use with TriNav reception fro optimum accuracy.

Supports both the traditional GPS (US) satellite position system, the GLONASS Russian system and the European Galileo system.

Support for the improved accuracy given by the WAAS and EGNOS Satellite-Based Augmentation System is also available. Features up to 72 satellites and up to 18Hz update rate.

Output is the standard NMEA 0183 - a USB version is also available.

Supplied with 10m cable or 5m USB cable if USB version selected and user manual.
Compatible with all versions of seaPro

Specifications

• NMEA 0183 version supplied with a 10m cable
• USB version supplied with a 5m USB cable
• 72 channel precision GPS/GLONASS/Galileo positioning sensor.
• Works with all versions of seaPro
• Ultra tough, waterproof construction
• Update rate up to 18Hz (user selectable)
• Configurable in the field using simple DIP switches inside the antenna
• Fast updates to optimize positioning information in slow and high speed applications
• WAAS/EGNOS/SBAS enabled for sub 1m accuracy
• User selectable GPS/GLONASS/Galilo mode or auto selection
• NMEA 0183 version compatible with NMEA 0183 equipment such as DSC radios, Chart plotters etc.
• NMEA output configurable for 4800, 38400 and 115200 baud (Serial and USB versions).
• Support muliple NMEA 0183 sentences DTM/GBS/GNS/GRS/GSA/GST/GSV/RMC/VLW/ GLL/GGA/VTG/ZDA
• Configurable in the field using simple DIP switches inside the antenna
• Small size 75mm in diameter/75mm height and designed to fit industry standard 1” x 14TPI threaded mounts
• Power requirements:
  USB version - self powered via USB port
  NMEA 0183 version 5 to 30v DC (<20mA at 12v)
